When high production capacity and quality matter, you need MWZ 1650G. With advanced gear drive technology, this machine can achieve 5,500 sph for bulk production. Based on R&D’s repeated deliberating and tests, every spare part we choose is for highest yield and quality.

Wanlian corrugated board production line comprises such equipment as Mill Roll Stand, pre-heater/pre-condioner, single facer, glue machine, double facer, Slitter Scorer, Helical Cross Cutter, Stacker, etc., and full-process intelligent control is performed for air compression system, glue preparation system, electrical control system, which reduces the labor intensity of operator, reduces the cost and realizes high efficiency.

This series is our part of our economical range.They are able to handle all grades of corrugated board from1-8.5mm.Generous speeds up to 4,800sph on some models, all with lead edge feeder,complete stripping.

high speed/ high stable / taiwan quality hsieh hsu machine is professional cardboard making machine supplier , can make 2/3/5/7 layer cardboard.our machine 5layer only use 4-5 persons .

Automatic Single-face Dry-end Corrugated Cardboard Production Line

This series is our part of our economic range.They are able to handle all grades of corrugated board from 1-8.5mm.Generous speeds up to 4,800 sph on some models,all with lead edge feeder,complete stripping.

?Foshan City Fuli Packaging Machinery Co., Ltd. is specialized in the design, assembly and manufacture of regular and high-end 3-layer, five-layer and 7-layer corrugated paperboard manufacturing lines with the breath ranging from 1.2 to 2.5 meters and designing rate from 120meter/minute to 250m/min. Firstly the corrugating medium scroll is fed from a roll stand and after being heated and humidity regelated by a pre-heater, it’ll enter a single facer to be rolled into the required shape and be glued to a liner-board to form a single-faced paperboard. Through over bridge traction, the single-faced cardboard will go through a multi-heater to be heated once again, then a glue applying machine applied glue to it before it’s fed into a double facer and heated for lamination. There a multi-faced paperboard comes into being. Then a slitter scorer will do a longitudinal slit and make a score, a cross cutter will then make precise horizontal and vertical cuts according to specifications required by customers. Lastly, a stacker will stack the lot together and take the counts, the final products of a complete manufacturing line will now be delivered by the stacker. The current development of the carton industry is demanding better paperboard making machinery. To survive fierce market competition and the pressure of high costs, choosing manufacture equipment that can meet the requirements of carton producing companies is a matter of profitability and life and death. Fuli’s machinery well serves the purpose of quality and efficiency boost as well as resource, labor, material saving and waste reduction. We seek no end in innovation to provide cost-efficient and energy-saving corrugated paperboard manufacturing machines.

This series is our part of our economic range.They are able to handle all grades of corrugated board from 1-8.5mm.Generous speeds up to 4,800sph on some models, all with lead edge feeder,complete stripping.

N.C. Slitter Scorer ZC35 ? Every group of knife stands and creasing wheel stands is moved by gear structure which driven by servo motor, it is positioning precisely and requiring only simple maintenance. ? Every group of knives or creasing wheels works with position sensors, which are tracking and controlling the real-time position of knives and creasing wheels precisely, once is a dis-aligned one is found, it will automatically retify it and eliminate the working tolerance. ? There are three types of creasing wheels : Male to Female. Male to Male, and Male to Flat. All changes are controlled by servo system, which makes free creasing combination. ? The bottom creasing wheels and the flat roll are driven by motors , which is synchronic with the whole line speed by the transducer. ? The creasing depth can be micro adjusted by servo motor, which controls the creasing depth precisely. ? The minimum creasing distance between in single machine is 70mm. With double machine the minimum creasing distance can reach zero. ? The top knife structure are combined with a comb-type anvil. The bottom comb-type anvil are made of carbon, easy for maintenance and last longer. ? Double Machines are connected by bottom connection stand and the pre-embedded rails, the connection stand and embedded base are completed by CNC center in one time, making sure the 0 scoring order in double machine combination.
